THE16 SUB ACTIVE SEALED adalah subwoofer aktif 16 inci yang menawarkan performa bass mendalam, hentakan kuat, dan respons ultra-cepat dengan harga terjangkau. Dirancang secara inovatif, subwoofer ini mampu memuat driver besar ke dalam sealed enclosure (boks tertutup) yang sangat ringkas, nyaris seukuran subwoofer 12 inci.
Fitur Utama:
Desain Driver 16″ Ringkas & Presisi: Menggunakan cone tiga lapis dengan inti Rohacell yang ringan namun kaku, serta motor magnet triple-stack. Memiliki pergerakan linear ekstrem (42mm Xmax) untuk menghasilkan bass yang akurat tanpa distorsi.
Tenaga Amplifier 1 kW: Didukung amplifier bertenaga 1000W (RMS) dengan suplai daya SMPS auto-sensing (110V-230V), memastikan performa dinamis yang bertenaga dan bersih.
Konektivitas & Kontrol Lengkap: Dilengkapi input LFE XLR balanced (tanpa pemrosesan untuk integrasi prosesor surround), dua input RCA dengan crossover variabel (50-150Hz), kontrol fase, kenop gain, serta input trigger 12V untuk otomatisasi daya yang aman.
Uncompromising Value & Power
Building on the success of THE12 SUB ACTIVE, THE16 SUB ACTIVE SEALED was developed in direct response to customer and dealer demand for a larger active subwoofer at an approachable price point. The mission was clear: Deliver greater extension, exceptional punch, and lightning-fast response in a compact enclosure.
The result is a subwoofer that feels as powerful as it is precise. THE16 SUB ACTIVE SEALED delivers incredible performance for its size, combining speed, depth, and control in a way that must be experienced to be understood.
Compact Precision
THE16 utilizes a sealed enclosure, chosen for its ability to deliver superior accuracy, transient response, and musicality. Despite housing a much larger driver, the enclosure remains remarkably compact, only slightly larger than THE12.
Amplification & Integration
Our amplifier section uses an auto-sensing SMPS power supply that supports worldwide mains voltages from 110V to 230V, ensuring clean and efficient power delivery anywhere in the world.
THE16 SUB ACTIVE SEALED – Combining speed, depth, and control in a compact masterpiece.
Speaker Type
16” forward-firing compositive cone woofer, 3” voice coil
XMAX
20 mm excursion each direction (40 mm linear), voice coil remaining in homogeneous magnetic field, linear and lower distortion
Principle
Sealed
Passive | Active
Active, built in DSP Amplifier
Dimensions (W/H/D) inch (Without Grille)
520 | 485 | 420 (Height without feet: 470) (Depth with plug: 480)
Dimensions (W/H/D) inch (Without Grille)
20 1/2 | 19 1/8 | 16 9/16 (Height without feet: 18 1/2) (Depth with plug: 18 7/8)
Packing Dimensions (W/H/D) mm
580 | 640 | 660
Packing Dimensions (W/H/D) inch
22 5/6 | 25 1/5 | 26
Weight
102.51 lbs | 46.5 kg
Gross Weight
116.84 lbs | 53 kg
Protection Features
Turn-on transients, Over-heating, DC, Short-circuit, Mismatched loads
Controller
LP crossover 40 Hz to 150 Hz variable, phase 0º-180º, volume control, auto tun on/off
Converter
N/A
Enclosure
Internally braced MDF
Finish
Black, White & Black Ash
Mounting
Floorstanding with feet
Grille
The THE16 SUB ACTIVE SEALED is supplied with a front cover as standard
Input
LFE: 1 x XLR Balanced Full Range / no crossover applied Line Level: 2 x RCA summing / unbalanced
Output
LFE: 1 x XLR Balanced Line Level: 2 x RCA / unbalanced
Power
IEC
SPL Peak (Peak / Half Space 2pi)
Measured Data 119 dB @ 33 Hz
Frequency Range
Measured Data (Without DSP) 35 Hz – 500 Hz / -3 dB 23 Hz – 500 Hz / -12 dB
Directivity Horizontal x Vertical in deg°
360°
Max Linear Air Volume Displacement
1.16 US. liq. gal. | 4.40 L
